DC-DC Converters REK15W Series
Product Information:
Model: REK15W
1in.×1in. Compact Size（25.4mm×25.4mm×10.0mm）
Wide Input Voltage (9V~36V,40-160V）
Positive Logic Control(3.5V to 15V turn on)
Output Voltage Adjust Rang:±10% of the rated output voltage
Output short-circuit protection, hiccup,auto-recovery
High efficiency 90% typ.(Input 24V, Io,max.)
1500Vac I/O Isolation Voltage
Operating Case Temperature:-40℃ to +105℃
Conforming to the EN50155 Standard Test
Warranty Period: 5-year
Applications: Industrial electronics & control and Rail transit & Railway.
Electrical Specification:
Input characteristic:
Input Voltage Range: 9-36Vdc,40-160Vdc
Output characteristic:
Output Voltage/Current : 5Vdc/3A
Line Regulation: ±0.2% max. Vo
Load Regulation: ±0.5% max. Vo
Ripple and Noise: 50mV ( typ.)
Temperature Coefficient: ±0.02%/℃
General characteristic:
Switching Frequency: 300KHz (typ.)
Efficiency: 90% (typ.)
MTBF: 2×106h @Bellcore TR332,Tc=25℃
Case Temperature: -40℃ to +105℃
Storage Temperature: -55℃ to +125℃
Shock And Vibration : Meets EN50155
EMC Specifications:
EMI Conducted Emission : EN55032 CLASS A
Surge Immunity: IEC/EN61000-4-5 line to line(±1kV/2Ω) CLASS B
Fast Transient : IEC/EN61000-4-4 ±2kV(5/50ns, 5kHz) CLASS A
