DC-DC Converters RAHS100-110B24KT-Y

Designed for 34-160V wide input 100W DC/DC Converters ,with features of half brick with Terminals and Al baseplate and Meets requirements of Standard EN50155

  • Item no.:

    RAHS100-110B24KT-Y
  • Product origin:

    China
  • Color:

    black+ Green
  • Min order:

    20
  • Shipping port:

    FOB Beijing
  • Lead Time:

    8-10 Weeks
  • Product Details

DC-DC Converters RAHS100-110B24KT-Y


This series are widely used in Telecommunication electronic data processing, distributed power architecture, Industry and Rail transit& railway application


Product Information:

Half-brick with Terminals and Al baseplate (85.0mm×61.0mm×29.7mm)

Positive Logic Control3.5V to 15V turn on

Input Undervoltage Protection27V to 34V turn off

Input Overvoltage Protection (180V to 190V turn off), auto-recovery

Output Overvoltage Protection30V to 34.8V

Output Voltage Adjust Range:±10 % of the rated output voltage

Output Short-circuit Protection, hiccup, auto-recovery

Typical efficiency up to 87%(110V,full load)

3000Vac Isolation Voltage

Operating Baseplate Temperature (-40 to +100)

Operating Ambient Temperature   (-40 to +70)

Over Temperature Protection: 120 Typ.

Meets requirements of Standard EN50155

Warranty Period: 5-year


Electrical Specification:

Input characteristic:

Input Voltage Range: 34-160Vdc


Output characteristic:

Output Voltage/Current : 24Vdc /4.2A

Line Regulation:   ±0.2% max. Vo

Load Regulation:  ±0.5% max. Vo

Ripple and Noise: 200mV (Max.) @20MHz bandwidth


General characteristic:

Switching Frequency: 200KHz (typ.)

Efficiency: 87% (typ.)

MTBF: 2×106h @Bellcore TR332,Tc=25℃

Operating Case Temperature: -40℃ to +100℃

Storage Temperature: -55℃ to +125℃

Temperature Coefficient: ±0.02%/℃

Shock And Vibration : Meets  EN50155 / EN61373


EMC Specifications:

EMI Conducted Emission : EN55032 CLASS A

Surge Immunity:  IEC/EN61000-4-5    line to line(±1kV/2Ω) CLASS B

Fast Transient :     IEC/EN61000-4-4    ±2kV(5/50ns, 5kHz)  CLASS A


Our Services:

17 years experience of converter industry.

5 Years Warranty.

Fast response for any question within 24 hours.

Full technical support before/after sales.

Customized products available (OEM, ODM).

ROHS Compliance


FAQ:

Q: what can you buy from us?

A: AC-DC Converter,DC-DC Converter,Power Module, Power Converter,Module Power Supply


Q: Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.


Q: Is it acceptable to print my logo on the product?

A: Yes. based on a certain purchase quantity,we can make OEM logo.


Q: Do you offer guarantee for the products?

A: Yes, we offer 2 or 5-year warranty for our products.


Q: What if I cannot find what I need on your products list?

A: What we list are standard types of AC-DC Converter,DC-DC Converter, if can't find what you needed, please tell us, we will send you the technical datasheet on email.
