DC-DC EMI Filter TFL100A20
Product Information:
Model: TFL100A20
Compact size：50.8mm×40.6mm×12.7mm
PCB Mount
Up to 20A output current
Up to 100V permanent input voltage.
Attenuation to 45 DB at 500 kHz,Differential Mode, typical
Attenuation to 55 DB at 500 kHz, Common Mode, typical
Typical Resistance 10mΩ
1500Vdc Isolation Voltage
Operation Case Temperature -40℃~+100℃
Suitable for use with Half Brick and Quarter Brick Series.
Electrical Specification:
Input characteristic:
Input voltage range: 0~100 Vdc
Output characteristic:
Output current : 20A @ Operation Case Temperature 105℃
General characteristic:
Attenuation to 55 DB at 300 kHz, Common Mode, typical
Attenuation to 45 DB at 300 kHz, Differential Mode, typical
Typical Resistance 10mΩ
1500Vdc Isolation Voltage
Operation Case Temperature -40℃~+100℃
Storage Temperature: -55℃ to +125℃
Our Services:
15 years experience of converter industry.
5 Years Warranty.
Fast response for any question within 24 hours.
Full technical support before/after sales.
Customized products available (OEM, ODM).
CE,ROHS Compliance
FAQ:
Q: what can you buy from us?
A: AC-DC Converter,DC-DC Converter,Power Module, Power Converter,Module Power Supply,DC filter and
transient protector,DC EMI input filter
Q: Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q: Is it acceptable to print my logo on the product?
A: Yes. based on a certain purchase quantity,we can make OEM logo.
Q: Do you offer guarantee for the products?
A: Yes, we offer 2 or 5-year warranty for our products.
Q: What if I cannot find what I need on your products list?
A: What we list are standard types of AC-DC Converter,DC-DC Converter, if can't find what you needed, please tell us, we will send you the technical datasheet on email.
